Products / Hyperspectral Cameras / Cubert Cameras
BD&E distributes Cubert’s hyperspectral cameras for their broad wavelength coverage and high-resolution spectral data. These true snapshot imagers capture full datacubes instantly—no scanning required—making them ideal for real-time analysis.
Cubert cameras are used in precision agriculture, environmental monitoring, food quality inspection, medical imaging, and remote sensing. They help detect plant stress, identify contaminants, and classify materials with high accuracy.
Easy to integrate, these systems deliver fast, reliable results in both lab and field conditions. Optional housings are available for underwater use or high-heat environments. Explore our models below or contact our team for a demo or consultation.
The XMR excels in a variety of applications,
including object tracking, surveillance,
and dynamic monitoring. Its versatile
capabilities make it suitable for numerous
sectors, ensuring enhanced performance
and reliability where you need it most.
Based on our hyperspectral light field camera technology, the ULTRIS SWIR 1 offers a versatile imaging solution with its broad wavelength range (980-1650 nm) within the Short-Wave Infrared region.
The Cubert ULTRIS 5 HFR is the newest addition to the ULTRIS series with all the benefits of the versatile Ultris 5: a resolution of 290 x 275 Pixels and 51 spectra but with record-setting non-scanning snapshot datacubes operating at 79 Hz.
Cubert extends their family of award winning Light Field snapshot Hyperspectral cameras with the new ULTRIS 5, packing a 5 megapixel sensor into a 30 x 30 x 50 mm package, the ULTRIS 5 records complete data cubes of 250 x 250 pixels and 51 spectral bands at 15 Hz across its 450-850 nm waveband.
The ULTRIS X20 Plus takes the capability of the ULTRIS platform to the next level. By incorporating a pan sensor to work in conjunction with the 410 x 410 native sensor, it is possible to achieve a resolution of 1880 x 1880 pixels.
Building on the success of the ULTRIS 20 and ULTRIS 20 Plus, the ULTRIS X20 offers a larger wavelength range of 350-1000nm, enabling UV-VIS-NIR coverage in a platform weighing less than 350g. The ULTRIS X20 is perfectly suited for any application from lab to UAV.
| Model | Band | Data Cube | Spectral Sampling | Cube Rate | Datasheet | ||
|---|---|---|---|---|---|---|---|
| # | (nm) | Spatial Pixels | Spectral Pixels | (nm/pixel) | (Hz) | ||
| HPATM Hyperspectral Imagers Snapshot and video rate data-cubes with high spectral/low spatial content |
|||||||
| FireflEYE v185 | 450-950 | 50 x 50 | 125 | 4 | 25 | Download | |
| ULTRIS 5 | 450-850 | 250 x 250 | 51 | 8 | 15 | Download | |
| ULTRIS 5 HFR | 450-850 | 290 x 275 | 51 | 8 | 75 | Download | |
| ULTRIS X20 | 350-1000 | 410 x 410 | 164 | 4 | 8 | Download | |
| ULTRIS X20 Plus | 350-1000 | 410 x 410 | 164 | 4 | 8 | Download | |
| ULTRIS SWIR1 | 980-1650 | 200 x 200 | 18 | 80 | Download | ||
Interested in learning about other hyperspectral cameras and the benefits of the innovative technology HyperPixel ArrayTM? Check out Bodkin Design & Engineering’s product line
All of our hyperspectral imaging systems produce data that is compatible with ENVI Image Processing & Analysis Solutions.
