Monarch Pro Hyperspectral
Camera

All Products › Monarch Pro

510 nm 930 nm 510–930 nm

The Unispectral Monarch Pro represents a major advancement in hyperspectral imaging, combining intuitive operation with exceptional cost efficiency. Designed to replace complex and fragile systems, it simplifies spectral data acquisition without sacrificing performance or context. Its streamlined design and accessibility lower barriers to adoption, making hyperspectral technology more practical for OEM integration, industrial inspection, research, and high-volume applications. With its scalable, user-friendly approach, the Monarch Pro expands the reach of spectral imaging across a wide range of industries.

Discover exceptional performance and value with a leading hyperspectral camera—ideal for OEM integration, system developers, industrial inspection, and advanced research applications.

Monarch Pro Technical Specifications
Spectral Channels
181 / 208
Spectral Band Range
500–700 nm; 700–930 nm
Spectral Accuracy
±5 nm
FWHM
25 nm ±5 @ image center
Spectral Center Wavelengths
510–690 nm; 713–920 nm
Image Resolution
1280 × 1024 px
Frame Rate
60 FPS (single-band mode)
Exposure Time
1–500 ms
Working Mode
Single frame / spectral image cube
Data Format
ENVI (RAW) & PNG
F/#
4.7
EFL
4.98 mm
Field of View (H-V-D)
31.5° × 25.5° × 39.8°
Input Voltage
5 VDC
Power Consumption
<1.6 W (Peak)
Peak Current
0.32 A
Interface Protocol
USB 3.0
System Compatibility
Windows / Linux / Android
Development Tools
Python / C API
Size
84 × 80 × 23 mm
Operating Temperature
0–70 °C
Humidity
<90%
Material
Aluminum Alloy 6063
Thermal Equilibrium Temp
35 °C
Design
Oil-proof, moisture-proof, dust-proof

Specifications:

High-Speed Imaging: Captures dynamic scenes at up to 60 frames/s in single-band mode

Spectral Range: 510–690 nm; 713–920 nm, continuously adjustable for flexible speactral acquisition

Platform Compatibility: Works with Windows, Linux, and Android via API for seamless integration

Data Transfer: USB 3.0 high-speed interface for reliable and fast data capture

Rugged Design: Oil-proof, moisture-proof, and dust-proof for demanding lab, agricultural, and industrial environments

Compact Form Factor: Small and lightweight for easy integration into space-limited setups

Versatile Applications: Ideal for agriculture, industrial inspection, research, and material analysis

Its compact, lightweight design and real-time snapshot imaging make it perfect for drone-based aerial mapping and remote sensing, delivering precise data on vegetation health, water quality, and land surface conditions.

Aerial Mapping & Remote Sensing

Its lightweight design and real-time hyperspectral imaging make it ideal for marine and ocean applications, providing rapid, contact-free analysis of water quality, algal blooms, and coastal ecosystem health.

Marine & Ocean Monitoring

Its compact design and real-time hyperspectral imaging make it ideal for factory inspection and food quality monitoring, enabling rapid, contact-free analysis of freshness, contaminants, and product consistency.

Inspection for Food & Manufacturing

Its compact, high-resolution hyperspectral imaging enables rapid, non-invasive analysis in biomedical and life science applications, supporting tissue diagnostics, cellular studies, and real-time spectral monitoring.

Biomedical & Life Science Imaging

Embedded/fixed applications

The Monarch Pro is a highly versatile hyperspectral camera designed for seamless integration with robotics, precision agriculture systems, and fixed installations such as greenhouses and vertical farms, combining rugged, industrial-grade durability with advanced API and SDK support for flexible customization, while its intuitive interface enables efficient data capture and streamlined analysis, ensuring reliable performance in demanding real-world environments including vibration, shock, humidity, and changing environmental conditions.
